Brix Sensors

The Inmec Brix Sensors are designed for measuring Brix throughout the sugar manufacturing and refining processes, with the accurate and stable measurement serving as a foundation for reliable process control. Digital microwave technology and a durable sensor design provide exceptional reliability to stand demanding process conditions.



High measuring resolution with sustaining non-drift stability are key factors to fulfilling the process control requirements. Our Digital Microwave Technology combined with a multivariable measuring algorithm, featuring several combined variables define Brix over a broad range and over wide process temperature fluctuations.

In-Line Brix Sensor

Model IL, In-Line Brix Sensor

The Model IL, In-Line Brix sensor is applicable for a large variety of Brix measurement needs throughout the sugar manufacturing and refining processes, where a wide measuring range and high stability are appreciated.

The sensor inserts trough a vessel wall sealed with quick coupling and provides highly representative and linear Brix measurement throughout a broad Brix range. It is an integrated, stand alone unit with 24VDC input and 4-20mA Brix output. Wiring is connected via a Connection unit.

The most common application for the probe is crystallizer pan control. However, the IL is also applicable in large diameter pipelines, min. 130mm, to measure Brix of sugar juices on a broad range of 0-95 °Bx.



Technical briefly:

-In-Line model for vessel wall installation
-Brix measuring range 0-95
-4-20mA output
-Process insertion 254mm
-Flange DN adapters
-Custom flange adapters on request

📋View data sheets

View product
Flow through Brix Sensor

Model G2, Flow through Brix Sensor

2" Pipeline

The Digital Microwave based flow through Brix sensor is applicable for dissolved and suspended solids in a range of 0-95%. The Model G2 is approved by EHEDG for hygienic applications in the sugar, food & beverage and the dairy industry. In sugar manufacturing the G2 sensor is used for liquid sugar Brix measurement on a wide range throughout the sugar manufacturing and refining processes.

📋View data sheets

View product
Flow through Brix Sensor

Model G3, Flow Through Brix Sensor

3" pipeline

The Digital Microwave based sensor is applicable for dissolved and suspended solids in a range of 0-95%. The Model G3 is designed for large volume lines. The Sensor is used for solids and Brix measurement on wide range throughout manufacturing and refining processes.

📋View data sheets

View product
Flow through Brix Sensor

Model G3, Flange DN80/PN16

3" Pipeline

The Digital Microwave based sensor is applicable for dissolved and suspended solids in a range of 0-95% . The Model G3 flange version is designed for high volume lines with requirement of bolt flange installation. The Sensor is used for solids and Brix measurement on a wide range throughout the manufacturing and refining processes.

📋View data sheets

    View product
