SKU: E700005
Model P2
Continuous in-line measurement for 2″ industrial pipelines
2″ Pipeline Sensor for Brix, Total Solids & Density Measurement
Continuous in-line concentration measurement directly in 2″ industrial process pipelines. The sensor measures total solids content — including both dissolved and suspended components — delivering stable, real-time data under normal flow conditions without bypass loops or sample extraction. Designed for industrial applications including sugar processing, chemical manufacturing, mineral processing, and industrial starch production where robust measurement and coating resistance are essential.
Sugar & Sweeteners
- Raw juice and thin juice transfer lines
- Filter backwash monitoring
- Molasses transfer and blending
- Industrial-grade syrup processing
Chemical Manufacturing
- Caustic solution concentration
- Acid concentration monitoring
- Salt solution and brine streams
- Chemical recovery and recycling
Mining & Mineral Processing
- Slurry concentration monitoring
- Tailings density measurement
- Leach solution concentration
- Process water recycle streams
Industrial Starch & Glucose
- Glucose syrup production lines
- Corn steep liquor monitoring
- Maltodextrin processing
- Industrial sweetener manufacturing
- Measurement range (Brix / solids):
0-95% Factory configured to specific TS or Density range by customer specification - Accuracy & repeatability:
+/- 0.01 % concentration - Sensitivity:
+/-0.001% concentration - Measuring resolution:
0.01% concentration - Outputs:TS % & Temperature,
4 – 20 mA, Active and Isolated. Max load 750 Ohm. - Process conditions:
- Ph= 3-14
- Temperature=0 – 140 C.
- Pressure: recommended min 1.5 bar to avoid free air
- Sensor body: Aisi 316L.
Flanged process fitting.
Control the process where it flows — inline, in real time.
Slurry measurement in our process lines was always problematic. This sensor handles high solids content and abrasive conditions without drift — finally getting reliable data for process control.
— Process Control Engineer, Mineral Processing (Switzerland)
3-year warranty
A full, industry-leading warranty reflecting confidence in long-term performance.
Stable signal despite coating and buildup
Maintains a stable measurement signal even when product coating or buildup is part of normal operation
Wide Measurement Range
Accurate measurement from low concentrations to high-solids processes — one sensor covers your full production spectrum.
Find the Right Configuration for Your Process Pipeline
Share your process details and our engineers will recommend the right configuration.
Explore Tank and Vessel Models
Looking for In-tank measurement instead? View our complete range of in-tank Sensors.
